Antistatic, antibacterial, antifungal flexible duct HDPE63A, 50 m roll
PRICE:
166.35 € 369.67 €
Qty.:
European delivery - 30 working days, other countries +7 working days.
Ask a question about this item
Ask a question about this item
Antistatic, antibacterial, antifungal flexible duct HDPE63A, 50 m roll
- antistatic
- antibacterial
- antifungal
- extremely durable
- the inner side of the duct is white plastic covered antistatic, antibacterial and antimold coating with silver oxide ions
- mechanical strength rating: 450 N
- the smooth-bore ducting provides very low pressure losses
- temperature resistance: combustible; softening point at 130 ˚C, flash point at 350 ˚C
- fire resistance class: B2
- operating temperature: -20 ˚C +60 ˚C
- 50 m roll
- weight of roll 15 kg
Selection of diffuser and air distributor (A, B, C, D)
|
Diffuser Ø, mm
|
Diffuser usefull area Ø, mm | Diffuser usefull area, cm2 |
Ø75 mm HDPE duct, P~31.2 cm2
|
Ø90 mm HDPE duct, P~44.2 cm2
|
| recommended duct connections to the distributor | ||||
|
80
|
60 | ~28.3 |
1
|
1
|
| 100 | 70 | ~38.5 | 1 | 1 |
| 125 | 100 | ~78.5 | 2 | 2 |
| 160 | 140 | ~154 | 5 | 3 |
| 200 | 160 | ~201 | 6 | 4 |
Selection of main air distributor (D, E, F, G) connected to heat recovery unit
|
HRU connectors Ø, mm
|
HRU connectors area in cm2 |
Ø75 mm HDPE duct, P~31.2 cm2
|
Ø90 mm HDPE duct, P~44.2 cm2
|
| recommended min. number of duct connectors in air distributor | |||
| 125 | ~122.7 | 4 | 3 |
| 160 | ~201.0 | 6 | 4 |
| 200 | ~314.2 | 10 | 7 |
Brand: ESEM
|
Code
|
ØD (outer)
|
Ød (inner)
|
Ø of roll | height of roll |
| HDPE50A | 50 | - | - | - |
|
HDPE63A
|
63
|
51 | ~1000 | ~300 |
| HDPE75A | 75 | 63 | ~1200 | ~400 |
| HDPE90A | 90 | 75 | ~1200 | ~500 |
| HDPE160A | 160 | 135 | ~1600 | ~500 |
| HDPE200A | 200 | 175 | - | - |
